BMW M3 GTS is the most extreme M3 ever

The BMW M3 GTS is largely hand-built by the most skilled craftsmen at BMW M GmbH as a perfectly harmonised package of outstanding modifications, with production exclusively to the customer’s personal order. Focused on motorsport, the modifications comprise both the drivetrain, the suspension and the body of the car, as well as its interior. Market launch of the BMW M3 GTS will be in spring 2010.

Consistent lightweight technology.
Consistent lightweight construction, adjustable aerodynamic units, an increase in engine size and output on the V8 high-speed power unit and suspension technology meeting all the requirements of motorsport – all this gives the BMW M3 GTS a top position among high-performance cars built for Clubsport racing. Unladen weight according to the DIN standard is less than 1,500 kg (3,300 lb), the lightweight body comes with special mounts for six-point seat belts and a rollcage fitted behind the B-pillar.

V8 high-speed power unit: derived from motorsport, optimised for motorsport.
The eight-cylinder power unit of the BMW M3 GTS enlarged in size to 4.4 litres and boosted in output to some 450 hp boasts construction principles and technical details carried over directly from motorsport. A supreme surge of ongoing power throughout a wide range of engine speed characterises the outstanding performance of the V8 with its high-speed concept. The features typical of a motorsport engine include the crankcase made of a special aluminium-silicon alloy and constructed in bedplate design, individual throttle butterflies, anti-knock sensors with ion flow technology, and, wet sump oil supply optimised for supreme driving dynamics.

Seven-speed M DKG Drivelogic with race-bred gearshift.
Power is transmitted in the BMW M3 GTS by the M double-clutch gearbox with Drivelogic also available as an option on the regular production model. This seven-speed M DKG Drivelogic gearbox follows a principle also developed for motorsport, shifting gears without the slightest interruption of engine power. The transmission was developed specifically for a particularly powerful high-speed engine. The gearshift characteristics on the seven-speed M DKG Drivelogic have been tailored specifically to the modified power unit of the BMW M3 GTS and the driver is able to shift gears both through the selector lever on the centre console and through special M shift paddles on the steering wheel.

High-performance suspension with purpose-built brakes.
To convey the supreme power of the engine to the road in equally supreme style even under the most extreme conditions, the BMW M3 GTS comes with suspension technology likewise derived from the highest realms of motorsport. While the suspension is based on the front and rear axle of the BMW M3 Coupé, the rear axle subframe is bolted firmly in position and the suspension features adjustment threads on the dampers for individual variation of the inbound and rebound strokes.

The high-performance brake system of the BMW M3 GTS features fixed callipers with six pistons up front and four pistons on the rear wheels. The race-oriented set-up of DSC Dynamic Stability Control naturally considers the potential of the BMW M3 GTS. Different-sized tyres front and rear running on 19-inch M light-alloy Competition rims in double-spoke design ensure optimum transmission of acceleration and brake forces to the road.

BMW will only manufacture the M3 GTS to order and sell it at about €115,000 (US$170 614) per unit.
